Commercial Water Filtration Systems
| SYNCHROMATIC MEGACHAR High Flow Demand Carbon Filtration | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| HFD SERIES ( 1 ½" WATERLINE ) -- FLOW RATES OF 37 gpm -- 48 gpm PEAK [BFF-1 MODEL is to be used when pH is below 6.8. BFF-2 MODEL is to be used when pH is 7.5 or higher and/or minimal TANNINS are present.] Request Quote 9500 Valve Service Manual |
|||||||||
| MODEL# | HFD-BFF-1/5 | HFD-BFF-2/5 | HFD-BFF-3/5 | HFD-BFF-1/7 | HFD-BFF-2/7 | HFD-BFF-3/7 | HFD-BFF-1/8.5 | HFD-BFF-2/8.5 | HFD-BFF-3/8.5 |
| TANK |
13" X 54" 2.5 CUFT./TANK 200 lbs. |
14" X 65" 3.5 CUFT./TANK 350 lbs. |
16" X 65" 4.25 CUFT./TANK 450 lbs. |
||||||
| GAC | |||||||||
| WEIGHT | |||||||||
Manifold 2,3,4,5, or 6 units for higher flow rates of non interrupted softened water. For example: hotels, hospitals, laundries...
| MEGACHAR SERIES MODEL 2850 | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| 1 ½" WATERLINE ** FLOW RATES 44 gpm -- 55 gpm PEAK [BFF-1 MODEL is to be used when pH is below 6.8. BFF-2 MODEL is to be used when pH is 7.5 or higher and/or minimal TANNINS are present.] Request Quote 2850 Valve Service Manual 2850S Valve Service Manual |
|||||||||
| MODEL# | BFF-1-2850/3.5 | BFF-2-2850/3.5 | BFF-3-2850/3.5 | BFF-1-2850/4.5 | BFF-2-2850/4.5 | BFF-3-2850/4.5 | BFF-1-2850/7.5 | BFF-2-2850/7.5 | BFF-3-2850/7.5 |
| TANK |
14" X 65" 3.5 CUFT./TANK 300 lbs. |
16" X 65" 4.5 CUFT./TANK 350 lbs. |
21" X 62" 7.5 CUFT./TANK 490 lbs. |
||||||
| GAC | |||||||||
| WEIGHT | |||||||||
| MODEL# | BFF-1-2850/10 | BFF-2-2850/10 | BFF-3-2850/10 |
| TANK |
24" X 71" 10.0 CUFT./TANK 750 lbs. |
||
| GAC | |||
| WEIGHT | |||
| MEGACHAR SERIES MODEL 2900 | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| 2" WATERLINE ** FLOW RATES 84 gpm -- 105 gpm PEAK [BFF-1 MODEL is to be used when pH is below 6.8. BFF-2 MODEL is to be used when pH is 7.5 or higher and/or minimal TANNINS are present.] Request Quote 2900S Valve Service Manual |
|||||||||
| MODEL# | BFF-1-2900/3.5 | BFF-2-2900/3.5 | BFF-3-2900/3.5 | BFF-1-2900/4.5 | BFF-2-2900/4.5 | BFF-3-2900/4.5 | BFF-1-2900/7.5 | BFF-2-2900/7.5 | BFF-3-2900/7.5 |
| TANK |
14" X 65" 3.5 CUFT./TANK 162 lbs. |
16" X 65" 4.5 CUFT./TANK 300 lbs. |
21" X 65" 7.5 CUFT./TANK 440 lbs. |
||||||
| GAC | |||||||||
| WEIGHT | |||||||||
| MEGACHAR SERIES MODEL 3900 | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| 3" WATERLINE ** FLOW RATES 210 gpm -- 271 gpm [BFF-1 MODEL is to be used when pH is below 6.8. BFF-2 MODEL is to be used when pH is 7.5 or higher and/or minimal TANNINS are present.] Request Quote 3900 Valve Service Manual NXT2 Timer Manual |
|||||||||
| MODEL# | BFF-1-3900/10 | BFF-2-3900/10 | BFF-3-3900/10 | BFF-1-3900/17 | BFF-2-3900/17 | BFF-3-3900/17 | BFF-1-3900/25 | BFF-2-3900/25 | BFF-3-3900/25 |
| TANK |
24" X 71" 10 CUFT./TANK 660 lbs. |
30" X 72" 17 CUFT./TANK 785 lbs. |
36" X 72" 25 CUFT./TANK 1,140 lbs. |
||||||
| GAC | |||||||||
| WEIGHT | |||||||||
